CARGO TOWER
Goods Lift with Self-Supporting Structure
The Cargo Tower lift is designed for flexible installation in ceiling openings, on shelving systems, or alongside landings. Its fully self-supporting structure requires only simple fixing at floor levels and the shaft head, keeping installation quick and straightforward.
Available as a complete solution on request, the Cargo Tower lift can be supplied with full-height cladding. This significantly reduces on-site work and streamlines the overall installation process.
Speak to an expert
0330 520 2319
SPACE-SAVING DESIGN
SAFE & RELIABLE
BUILT TO LAST PERFORMANCE
VERSATILE FOR MANY INDUSTRIES
Basic Data
-
Load Capacity 500kg to 2,000kg
-
Up to 3 access sides (depending on load capacity)
-
Landing doors as single or double-leaf swing door
-
Drive unit arrangement at the top or on the side next to the shaft
-
Nominal speed up to 0.15 m/s
-
Optionally with safety gear on the tensioning or balancing weights for accessible spaces under the shaft
Basic Equipment
-
Hot-dip galvanised car and landing doors
-
Self-supporting hot-dip galvanised shaft structure
-
Short assembly times due to pre-assembled components
-
Drive with compact worm gear
-
Microprocessor control completely pre-wired and pluggable in 24 volt technology
-
Call and send control including key switch for limited user group
-
Call acknowledgement, arrival signal and position indicator
-
Diagnostic system
-
LED car lighting
-
LED shaft lighting
Optional
-
Cladding of structure with hot-dip galvanised sheet steel
-
Car closure or load restraint
-
Frequency control
-
Overload proteciton
-
Materials and surfaces according to customer requirements
-
Intercom systems
-
Ship designs
-
Water/dust protection (IP)
-
Special solutions for reduced shaft conditions
-
Deviating car dimensions
-
Further special solutions on request
NOTE: The Cargo Tower PLUS lift comes with the option to include an attendant during travel. Please enquire for more information.
